REV. A
KMT12/KMT18
25
Notes for data
1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ
standard.
2. Measured @4 mt then scaled @1 mt
3. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the
amplifier will produce into the nominal load impedance.
New materials and design are introduced into existing products without previous notic e. Present systems
may differ in some respects from those presented in this brochure.
Acoustics
Speakers power
handling
800 w
(EAS)
Maximum power 1400 w
1
Impedance 8Ω
Frequency range 30Hz - 150 Hz +/- 3dB (preset dependent)
SPL 1W/1mt 99 dB
2
Maximum SPL 130 dB continuous - 136 dB peak
Coverage
Omni
Crossover
Type DSP controlled
Frequency 150 Hz maximum (preset dependent)
Transducers
1 x 18” Neodymium speakers with 3”
voice coil
Audio Input
Analog
Connectors
2 male + 2 female 3-pin balanced XLR
Digital
Connectors
1 male + 1 female 3-pin XLR
Audio powered Output
Connector Female Speakon
Wiring
Pin1+= CH1+ Pin1= CH1- Pin2+= N.C.
Pin2= N.C.
Remote control Input
Connectors 1 male + 1 female XLR parallel
1 USB B Jack serial converter
Power Input
Connectors 2 x PowerCon IN/OUT
Amplifiers
Type 1 modules class D - DSP controlled
Subwoofer power 1000 Watt
3
@8Ω
Speaker power
output
1000 Watt
3
@8Ω
Protection
Dynamic limiter, over current, over temp,
short circuits
AC power
Operating range 90 - 125 Vac 60Hz / 190 - 240 Vac 50Hz
(Auto Switch)
I. nom 410 W
Minimum
operation voltage
85 Vac - 185 Vac
Maximum
operation voltage
135 Vac - 250 Vac
Max continuos
and
burst current
6A(>10 sec) - 12A (<1 sec) @ 230V
10A(>10 sec) - 20A (<1sec) @ 115V
Physical
Dimensions
46.5 x 47.5 x 61 cm
(18.31”x 18.70” x 24.02”)
Weight 27.6 Kg (60.85 lbs)
KMT18
