K-ARRAY KMT18P [7/28] Introduction

REV. A

KMT12/KMT18

1. INTRODUCTION

The K-array KMT12 and KMT18 are full-featured audio systems featuring a powered subwoofer, programmable on-

board DSP and multiple analog and digital inputs and outputs for creating a wide array of speaker congurations.

The KMT12 features a 12” subwoofer, while the KMT18 features an 18” subwoofer.

The KMT 12 and KMT 18 feature an integrated touch screen, providing intuitive control over the main DSP

functions: input / output levels, signal routing, offset delays for subwoofer and speakon output (up to 12 ms.,

each) and overall system delay (up to 330 ms.). All DSP functions, including EQ, can also be remote controlled via

software over USB or RS485 (3-pin XLR).

The KMT series provides two balanced analog line level inputs and a two-channel AES/EBU digital input. An

integrated class D amplier delivers 2 x 1050 W at 8Ω, with a max THD of 1% (EIAJ test @ 1KHz). The KMT12 /

KMT18 feature multiple analog and digital outputs, including a Speakon output to connect a wide array of passive

speakers including mid-high modules (KK52, KK102) or additional passive subwoofers (KMT12P or KMT18P). To

optimize performance, the on-board DSP includes up to 40 programmable presets. The rst 8 have been designed

by K-array, the additional 32 slots can be used to create, save, and store personal presets using the K-framework

software.

The KMT series’ unique four-corner port conguration provides symmetrical back loading to the speakers, for

extended bass response with very low distortion. The port conguration also provides incredible structural strength

to the cabinet, despite its light weight. Pocket handles and an M20 thread mount position for attaching mid-high

speakers makes the Redline series convenient to use and ideal for medium throw applications in theaters, concert

halls, and Audio/Video installations.

All KMT components are designed by K-array and custom-made under K-array’s quality control system.

2. APPLICATIONS

• Theatrical sound reinforcement

• Concert halls, clubs, houses of worship

• Portable and installed audio-visual systems

• Cinema and special effects

3. KEY FEATURES

• Unique performance-to-size ratio

• Direct radiating, long excursion driver

• Ultra fast set-up and dismantling system

• Fitted with integrated handles and castors

• Analog and digital AES/EBU inputs

• Remote software control over USB and RS485

• Optimized for use with KK52 / KK102, KMT12P

/ KMT18P
