21
SHUTTER function (in AUTOMATIC MODE) is active only for CU01/CU16 and
Wh01/Wh16 macros.
ChPr MASTER/SLAVE
The first unit that will function as a Master must be set to Automatic mode (AUTO), the
other units must be set to Slave mode (SLAV), selectable through the menu. In this way
all the Slave units will be synchronised with the master and running their own ChPr
game.
On the master unit it is possible to vary the Speed time (SPEE) for the colour changhing
and the Wait time (UAIt) between the steps.
Speed time and Wait time on the Master, have priority on the slave units.
NB: It is possible to run GA.Pr on the other units even though these do not have GA.Pr
programmed. You can do this by setting the units to 10 channels DMX mode and
selecting DMX address A001.
REC MODE
It is possible to program your own game on the FOS 100 POWER SOLO that will then
run it in AUTO mode (ChPr).
Each unit can have its own programmed game.
In REC mode the unit must be set to 10 channels mode.
To program the ChPr by using a DMX controller, you need 3 more channels in addition
to the 10 channels necessary to control the unit.
So that in RECORDER mode (via DMX) the unit will need 13 DMX channels to be
correctly programmed.
The three new DMX channels are:
DMX channel 11 = SCENES channel:
- From 0-24 = no function
- From 25-255 the programmable scenes are displayed (max 16 scenes from M001 to
M0016 )
DMX channel 12 = EDIT channel:
- From 0-19 = no function
- From 20-234 the unit runs the configuration given by the received input DMX values.
With the channel SCENES it is possible to pass from one step to the next while with
REC it is possible to record the selected scene.
-From 235-255 the unit runs the configuration given by the received input DMX values,
closing the sequence as last scene.
With the channel REC it is possible to record the selected scene as last scene.
DMX channel 13 = RECORDING channel
Records the set scene with a variation between 0 to 255 (the display flashes indicating
that the scene has been recorded). It is advised that you keep the REC channel set to 0
and to run through the 255 only once you have decided to save the scene. If ChPr is not
closed, by indicating the last scene ( Edit channel between 235-255), in playback mode
all 16 scenes will be played through, even if not programmed
