12 - SERVICE MENU

For technical personnel only

To operate this menu:

-Connect the unit to the main

-While reset is running, press the MENU and ENTER keys at the same time.

CHANNELS

This menu allow to set 3 channels or 4 channels LEDs output mode

3 LEDs channels output mode = Not Used on FOS 100 POWER SOLO

4 LEDs channels output mode = Default

PRODUCT MODEL SELECTION:

- FOS 100 POWER = Default

- TITAN PLUS = only for TITAN PLUS unit

- DELTA 8= only for DELTA 8 unit

EXIT

Exit from hidden menu.

AUTOMATIC OPERATION (AUTO):

FOS 100 POWER SOLO can work in automatic mode without a DMX controller. First of

all connect the projectors with a DMX cable (picture below). A maximum quantity of 32

slave units can be connected to the same Master unit.

MASTER SLAVE 1 SLAVE 2 SLAVE 32

To activate Auto mode on the first unit, use the menu to run through the different modes

until AUTO appears on the display, and press enter.

Now it is possible to choose between the different pre-programmed games (CUPr-RAIn-

CU01/CU16-Wh01/Wh16) or ChPr which is user programmable through REC mode. To

confirm game activation press ENTER on the selected GAME.

CUPr-RAIn-CU01/CU16-Wh01/Wh16

The first unit that will work as a Master should be placed in Automatic mode (AUTO), the

other units have to be placed 10 channels DMX mode (MODE 10 CH) and the DMX

address should be set at A001. For RaIn (rainbow) game it is possible to select the

speed for the colour changhing (SPEE).

DIMMER function (in AUTOMATIC MODE) is active for all the programs.
