INPUT/OUTPUT CONNECTIONS
FOS 100 SOLO IP65 / FOS 100+ SOLO IP65
Mains 90-260 V Ac
50-60 Hz output ILME 5 pins
Female panel connector
MAX load:
230 V Ac = 20 FOS 100 SOLO
100 V Ac = 10 FOS 100 SOLO
DMX IN/OUT
ILME 4 pins Female
Panel Connectors
8
M12 LED output
Female panel connector
Mains 90-260 V Ac
50-60 Hz input cable
M12 LED input
Male cable connector
FEMALE PANEL
CONNECTOR
MAINS OUTPUT
1
3
2
4
FEMALE PANEL
CONNECTOR
DMX IN-OUT
LEDS
CONNECTOR PINOUT
4-GREEN -
5-BLUE +
6-BLUE -
7-AMBER - (RGBA / WHITE)
8-AMBER + (RGBA / WHITE)
1-RED +
2-RED -
3-GREEN +
LEDS
CONNECTOR
4-GREEN - (FC / RGBA / WHITE)
5-BLUE + (FC / RGBA / WHITE)
6-BLUE - (FC / RGBA / WHITE)
7-
1-RED + (FC / RGBA / WHITE)
2-RED - (FC / RGBA / WHITE)
3-GREEN + (FC / RGBA / WHITE)
FOS 100
Pin1
2
3
4
5
6
7
Pin1
2
3
4
5
6
7
8
8
DMX IN/OUT
ILME 4 pins Female
Panel Connectors
