16
Safety Agency Compliance
Complies with the requirements of
UL-2043
Fire Tests for Heat and Visible Smoke
Release for Discrete Products and their Accessories Installed in Air Handling Spaces,
NFPA-70
National Electric Code 1996, Article 300-22(C), and
NFPA-90A
Installation
of Air Conditioning and Ventilation Systems, Section 2-3.10.1 (a), Exception 3. Listed
UL1480-5
Speakers for Fire Protective Signaling Systems. For installation instructions
refer to JBL manual
#CLNG SPKR MANUAL
.
SUITABLE FOR USE IN AIR HANDLING SPACES.
These products are in compliance with the EMC Directive 89/336/EEC and Article 10 (1)
of the directive. In compliance with Technical Regulations EN50081-1 and EN50082-1.
For a copy of the model-specific CE Declaration of Conformity, contact JBL at the
address listed at the end of this manual.
Maintenance
No maintenance is required when installed in accordance with installation and wiring
guidelines described in this manual.
