MICROMIX MX400

Welcome to BEHRINGER

Thank you for showing your condence in us by purchasing the BEHRINGER MicroMIX MX400.

This 4-channel mixer is perfect for anyone wanting to mix 4 line level signals quickly and

without complications. Despite its compact size, thismixer produces highest signal quality

even at highest levels, in highest signalintegrity.

Connectors and Control Elements

(1)

(5)

(2) (3)

Ifmounting in a rack, ensure that the mains can be easily disconnected by a

plug or by an all-pole disconnect switch on or near the rack.

(2) Up to four line signal sources can be connected to these ¼" TS connectors (INPUT).

◊ In case the volume level of one of the signal sources is set too high, the input

(3) The OUTPUT carries the MIX signal and is on a ¼" TS connector.

(4) This ON LED is illuminated as soon as the unit is connected to the power.

(5) Using the LEVEL controls you can set the output level of each channel.

◊ High volume levels can damage your hearing or your headphones.

Pleaseturn down all volume controls to zero (allthe way to the left)

Applications

The following gure shows an example of how to use the MicroMIX MX400.

Example: MX400 wiring

Warranty

For our current warranty terms, please refer to our website at http://behringer.com.

Die deutsche Anleitung ist erhältlich @ behringer.com

Manuel francophone en téléchargement sur behringer.com

Manual en español disponible en behringer.com

Manuali italiani disponibili @ behringer.com

Русскоязычное руководство @ behringer.com

Polska instrukcja dostępna jest pod adresem @ behringer.com
