User Instructions
American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 2
American DJ®
Vizi Wash LED 108
Table of Contents
Unpacking......................................................................3
Introduction....................................................................3
Customer Support......................................................................3
Safety Precautions......................................................................4
Mounting..............................................................................5
General Information.....................................................................7
Features.........................................................................7
Registration......................................................................7
Controls and Functions..............................................................8
Set-Up.............................................................................11
System Menu............................................................................14
Editing Program.........................................................................29
Error Codes...............................................................................34
Operating Modes.......................................................................36
DMX Traits.................................................................................38
Fuse Replacement....................................................................40
Cleaning..................................................................40
Trouble Shooting.......................................................................40
Photometric Chart.....................................................................41
Warranty.................................................................42
Specifications....................................................................43
Содержание
- American d 1
- Table of contents 1
- User instructions 1
- Vizi wash led 108 1
- Customer support 2
- Introduction 2
- Unpacking 2
- Warning 2
- Notice the suitable enviromental temperature for this light ing fixture is between 25 c to 45 c do not place this lighting fixture in an enviroment where the temperatures are under or above the temperatures stated above this will allow the fixture to run at its best and help prolong the fixture life 3
- Screw one clamp each via a m12 screw and nut onto the omega holders insert the quick lock fasteners of the first omega holder into the respective holes on the bottom of the vizi wash led 108 tighten the quick lock fasteners fully clock wise install the second omega holder pull the safety cable through the holes on the bottom of the base and over the truss ing system or a safe fixation spot insert the end in the carabine and tighten the safety screw 3
- 5 6 2 7 4
- Caution 4
- Dmx 512 6
- Notice 6
- Power supply 6
- Special note line termination 6
- Conductor 5 pin xlr male in 3 pin xlr female out 7
- Data compliment signal 7
- Data true signal 7
- Ground shield 7
- Not used 7
- Pin 4 do not use 7
- Pin 5 do not use 7
- Pin xlr dmx connectors 7
- Pin xlr to 5 pin xlr conversion 7
- Some manufactures use 5 pin dmx 512 data cables for data transmission in place of 3 pin 5 pin dmx fixtures may be implemented in a 3 pin dmx line when inserting stan dard 5 pin data cables in to a 3 pin line a cable adaptor must be used these adaptors are readily available at most electric stores the chart below details a proper cable conversion 7
- Vizi wash led 108 set up 7
- Vizi wash led 108 system menu 7
- Addr main menu 9
- Test main menu 9
- Play main menu 10
- Rese main menu 10
- Time main menu 10
- Degr menu 11
- Fine menu 11
- Rpan menu 11
- Rtilt menu 11
- Disp main menu 12
- Mic menu 12
- Spec main menu 13
- Er tilt movement error if the head is not located in the default tilt position after start up or after a reset command this message will appear after a fixture reset if the tilt magnetic indexing circuit malfunctions sensor failed or magnet is missing or there is a stepper motor failure defective motor or a defective motor ic drive on the main pcb 18
- Operating modes the vizi wash led 108 can operate in three different modes this next section will detail the differences in the operating modes 18
- Play is displayed and press enter 3 18
- Stand alone sound active or auto program 18
- Universal dmx control 18
- 127 96 127 led on 19
- 159 pulse effect in sequences 160 191 led on 192 223 random strobe slow fast 224 255 led on 9 dimmer 0 255 intensity 0 100 10 rainbow effect 0 7 no function 8 231 rainbow colors 232 255 crossfading colors slow fast 11 pan tilt movement speed 0 225 max to min speed 226 235 blackout by movement 236 255 no function 19
- 255 pan movement 8bit 2 0 255 pan fine 16bit 3 0 255 tilt movement 8bit 4 0 255 tilt fine 16bit 5 red 1 255 0 100 6 green 1 255 0 100 7 blue 1 255 0 100 8 shutter strobe 0 31 led off 32 63 led on 64 95 strobing slow fast 19
- Channel value function 19
- Master slave operation sound active or auto program 19
- Play is displayed and press enter 3 19
- Channel value function 20
- Reset internal programs 0 79 color change normal 80 84 all motor reset 85 87 scan motor reset 88 99 no function 100 119 internal program 1 120 139 internal program 2 140 159 internal program 3 160 179 internal program 4 180 199 internal program 5 200 219 internal program 6 220 239 internal program 7 240 255 sound active program 20
- American d 21
- Audio products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of purchase see specific warranty period on reverse this warranty shall be valid only if the product is purchased within the united states of america including possessions and territories it is the owner s responsibility to establish the date and place of purchase by ac ceptable evidence at the time service is sought 21
- B for warranty service you must obtain a return authorization number ra before 21
- C this warranty is void if the serial number has been altered or removed if the product is 21
- D this is not a service contract and this warranty does not include maintenance cleaning 21
- E american dj inc reserves the right to make changes in design and or improvements 21
- Manufacturer s limited warranty a american dj inc hereby warrants to the original purchaser american dj and american 21
- Manufacturer s limited warranty periods all american audio products 1 year 365 day limited warranty except v plus series ampli fiers all american audio v plus series amplifiers 3 year 1095 day limited warranty american dj lighting and american dj branded products 1 year 365 day limited warranty such as special effect lighting intelligent lighting uv lighting strobes fog machines bubble machines mirror balls par cans trussing lighting stands etc excluding laser products lamps and star tec series american dj laser products and star tec products 90 day limited warranty american dj l e d products 3 year 1095 day limited warranty excluding motors which have a 1 year 365 day limited warranty 21
- Modified in any manner which american dj inc concludes after inspection affects the reliability of the product if the product has been repaired or serviced by anyone other than the american dj inc factory unless prior written authorization was issued to purchaser by american dj inc if the product is damaged because not properly maintained as set forth in the instruction manual 21
- Or periodic check up during the period specified above american dj inc will replace defec tive parts at its expense with new or refurbished parts and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship the sole responsibility of american dj inc under this warranty shall be limited to the repair of the product or replace ment thereof including parts at the sole discretion of american dj all products covered by this warranty were manufactured after january 1 1990 and bear identifying marks to that effect 21
- Sending back the product contact american dj inc service department at 800 322 6337 send the product only to the american dj inc factory all shipping charges must be pre paid if the requested repairs or service including parts replacement are within the terms of this warranty american dj inc will pay return shipping charges only to a designated point within the united states if the entire instrument is sent it must be shipped in it s original package no accessories should be shipped with the product if any accessories are shipped with the product american dj inc shall have no liability whatsoever for loss of or damage to any such accessories nor for the safe return thereof 21
- This warranty is the only written warranty applicable to american dj and american audio products and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published 21
- Upon its products without any obligation to include these changes in any products theretofore manufactured no warranty whether expressed or implied is given or made with respect to any accessory supplied with products described above except to the extent prohibited by applicable law all implied warranties made by american dj inc in connection with this product including warranties of merchantability or fitness are limited in duration to the warranty period set forth above and no warranties whether expressed or implied including warranties of merchantability or fitness shall apply to this product after said period has expired the consumer s and or dealer s sole remedy shall be such repair or replacement as is expressly provided above and under no circumstances shall american dj inc be liable for any loss or damage direct or consequential arising out of the use of or inability to use this product 21
- Vizi wash led 108 photometric charts 21
- Vizi wash led 108 warranty 21
- Www americandj com vizi wash led 108 instruction manual page 41 21
- Www americandj com vizi wash led 108 instruction manual page 42 american d 21
- American dj europe 22
- American dj supply 22
- American dj world headquarters 22
- Ew kerkrade 22
- Junostraat 2 22
- Model vizi wash led 108 22
- Netherlands 22
- Please note 22
- S eastern ave los angeles ca 90040 usa 22
- Service americandj eu www americandj eu 22
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 22
- Tel 31 45 546 85 00 fax 31 45 546 85 99 22
- Tel 323 582 2650 fax 323 582 2610 22
- Web www americandj com e mail info americandj com 22
