Model: Vizi Wash LED 108
Voltage: 120v~60Hz / 230v~50Hz
Power Consumption: 120W
LEDs: 36 x 3W (12 Red, 12 Green, &
12 Blue)
Dimensions: 12.25”(L) x 9”(W) x 14.5”(H)
310mm x 228mm x 369mm
Colors: RGB Color Mixing
Weight: 20 Lbs. / 9 kgs.
Fuse: 3A
Duty Cycle: None
DMX: 12 Channels
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 3 Years (1095 days
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Vizi Wash LED 108 Specifications
American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 43
©American DJ Supply
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-582-2610
Web: www.americandj.com / E-mail: info@americandj.com
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@americandj.eu / www.americandj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
