Features:
• Multi-Functional 2-Way Cabinet
• 500 W, 8 Ohms
• 90° x 50° Coverage Pattern
• 100 dB Sensitivity, 133 dB Maximum SPL
• Crossover with HF Protection
• SMX2151 LF Transducer
• DH3 Compression Driver
• Pole Mount for Tripod Use
• M8 Threaded Points
• Mounting Points to attach optional Mounting
Bracket
Technische Informationen
Engineering Data Sheet
C15.2
15“ / 1.25“
2-Way Fullrange Cabinet
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for “flying”
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
C 15.2
Order No. F01U165092
Cabinet Fullrange
Configuration Passive 2-Way
Nominal impedance 8 Ohms
Minimum Impedance 5.3 Ohms
Rated Power RMS 500 W
Peak Power 2000 W
Sound pressure level
SPL 1 W / 1 m 100 dB
Max. SPL 1 m (calculated
with peak power)
133 dB
Frequency Range (-10 dB) 57 Hz to 20 kHz
Nominal Coverage Angle
(Horizontal x Vertical)
90° x 50°
X-Over Frequency 1550 Hz
LF Transducer SMX2151, 15‘‘ (381 mm) Driver
HF Transducer DH3, 1.25‘‘ (32mm) Diaphragm Compres-
sion Driver
Connectors 2x Neutrik Speakon NL4
Full-Range 1+ / 1-
Wired through 2+ / 2-
Dimensions (W x H x D) 445 mm x 660 mm x 445 mm
(17.5“ x 26.0“ x 17.5“)
Net Weight 28.3 kg (62.4 lbs)
Shipping Weight 31.8 kg (70.1 lbs)
Enclosure material MDF with D-PUR PLUS
Grille Steel, Black Finish with Acoustic Gauze
Suspension 3x M8 threaded Points - 1x on Each Side and
1x on the Rear of Enclosure
Warranty 5 years
Optional Accessories
DC-MBC15-UMH F01U169671
TMA Tilt Angle for UMH F01U118977
RMA Rotatable Mounting kit F01U118976
TC-02 Truss clamp F01U100657
EBK-M8 Eye Bolt Kit F01U166797
Spare Parts
LF Transducer F01U134309
HF Transducer F01U103119
