American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 7
• DMX-512 Protocol Compatible (Uses 12 DMX Channels)
• 3 Operating Modes - Sound Active, Show Mode, DMX Control
• Internal Microphone
• Edit and Save Scenes into the Memory
• Variable Strobe (1-12 fps)
• Switchable 540˚ to 630˚ Pan Movement
• 265˚ Tilt Movement
• Digital Display for Address and Function Setting
Vizi Wash LED 108 Features
The Vizi Wash LED 108 carries a three year (1095 days) limited war-
ranty. Please fill out the enclosed warranty card to validate your
purchase. All returned service items whether under warranty or not,
must be freight pre-paid and accompany a return authorization (R.A.)
number. The R.A. number must be clearly written on the outside of the
return package. A brief description of the problem as well as the R.A.
number must also be written down on a piece of paper and included
in the shipping carton. If the unit is under warranty, you must provide
a copy of your proof of purchase invoice. You may obtain a R.A. num-
ber by contacting our customer support team on our toll free custom-
er support number. All packages returned to the service department
not displaying a R.A. number on the outside of the package will be
returned to the shipper at the shippers cost.
Vizi Wash LED 108 Product Registration
To optimize the performance of this product, please read these operating
instructions carefully to familiarize yourself with the basic operations of
this unit. These instructions contain important safety information regard-
ing the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
American DJ® will not accept any liability for any resulting damages
caused by the non-observance of this manual or any unauthorized
modication to this unit.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ®.
Vizi Wash LED 108 General Information
American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 8
Vizi Wash LED 108 Controls and Functions
REAR
FRONT
1
3 4 5 62 7
12
13
8 9
10
11
