American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 35
03Er – TILT movement error:
If the head is not located in the default tilt position after start-
up or after a reset command. This message will appear after a
xture reset, if the tilt magnetic-indexing circuit malfunctions
(sensor failed or magnet is missing) or there is a stepper motor
failure (defective motor or a defective motor IC drive on the
main PCB).
Vizi Wash LED 108 Error Codes
American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 36
Operating Modes: The Vizi Wash LED 108 can operate in three
different modes. This next section will detail the differences in
the operating modes.
• Stand alone mode -
The unit will react to sound, or chase through the built-in programs.
• Master/Slave mode -
You can daisy chain up to 16 units together to get a synchronized
light show without the need of an external controller. The units
will react to sound or chase through the built-in programs.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller such as the Elation® Show
Designer.
™
Universal DMX Control: This function allows you to use a uni-
versal DMX-512 controller such as the Elation® DMX Operator™ or
Elation® Show Designer™ to control head movement, color intensity,
shutter (strobe), and internal programs. A DMX controller allows you
to create unique programs tailored to your individual needs.
1. The Vizi Wash LED 108 uses twelve DMX channels. See pages
38-39 for detailed description of the DMX traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 11-13 as well as the set-up specifications that are
included with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instruction on page 16 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Stand-Alone (Sound Active or Auto Program): This mode allows
a single unit to run to the beat of the music or run through a built-in
program.
1. Access the main menu.
2. Tap the UP button until “PLAY” is displayed, and Press ENTER.
3. Tap the UP button until “AUTO” is displayed, and Press ENTER.
Vizi Wash LED 108 Operation
