American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 21
Vizi Wash LED 108 System Menu
4. Press MODE/ESC to return to the main menu.
CODE - Use this function to enter the “Clear Last Run”
password. Password is “038”.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press ENTER.
3. Tap the UP button until “CODE” is displayed, press ENTER.
4. Press ENTER to conrm.
5. Press MODE/ESC to return to the main menu.
CLFE - With this function you can clear the unit running
time.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press ENTER.
3. Tap the UP button until “CLMT” is displayed, press ENTER.
4. Press ENTER to conrm.
5. Press MODE/ESC to return to the main menu.
RPAN MENU -
RPAN - The movement of the Pan will be reversed.
1. Access the main menu.
2. Tap the UP button until “RPAN” is displayed, press ENTER.
3. Press the UP or DOWN buttons to select either “ON” to acti-
vate this function, or “OFF” to deactivate this function.
4. Press ENTER to conrm.
5. Press MODE/ESC to return to the main menu.
RTILT MENU -
©American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 22
Vizi Wash LED 108 System Menu
RTILT - The movement of the Tilt will be reversed.
1. Access the main menu.
2. Tap the UP button until “RTILT” is displayed, press ENTER.
3. Press the UP or DOWN buttons to select either “ON” to acti-
vate this function, or “OFF” to deactivate this function.
4. Press ENTER to conrm.
5. Press MODE/ESC to return to the main menu.
FINE MENU -
FINE - Switch between 8bit (coarse) and 16bit (ne) pan &
tilt movement. 16bit is the default setting.
1. Access the main menu.
3. Tap the UP button until “FINE” is displayed, press ENTER.
4. Press the UP or DOWN buttons to select either “ON” to acti-
vate this function, or “OFF” to deactivate this function.
5. Press ENTER to conrm.
6. Press MODE/ESC to return to the main menu.
DEGR MENU -
DEGR - With this function you can switch the Pan degree
between 540˚ (default) or 630˚.
1. Access the main menu.
2. Tap the UP button until “DEGR” is displayed, press ENTER.
3. Press the UP or DOWN buttons to select either “630” or
“540”.
4. Press ENTER to conrm your selection.
