Specifications
Directional characteristics
Supercardioid
Principle of operation
Pressure gradient
Cartridge type
Pre-polarized condenser
Frequency range
20 Hz - 20 kHz
Frequency range, ±2 dB, 20 cm (7.9 in)
80 Hz - 15 kHz with 2 dB soft boost at 10 - 12 kHz
Second order low-cut filter at 80 Hz with DAD4099-BC
Sensitivity, nominal ±3 dB at 1 kHz
d:vote™ for Loud SPL: 6 mV/Pa; -44 dB re. 1 V/Pa
d:vote™ for Extreme SPL: 2 mV/Pa; -54 dB re. 1 V/Pa
Equivalent noise level, A-weighted
d:vote™ for Loud SPL: Typ. 23 dB(A) re. 20 µPa (max. 26 dB(A))
d:vote™ for Extreme SPL: Typ. 28 dB(A) re. 20 µPa (max. 31 dB(A))
S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL)
d:vote™ for Loud SPL: 71 dB
d:vote™ for Extreme SPL: 66 dB
Total harmonic distortion (THD)
d:vote™ for Loud SPL: < 1 % up to 131 dB SPL peak
d:vote™ for Extreme SPL: < 1 % up to 137 dB SPL peak
Dynamic range
d:vote™ for Loud SPL: Typ. 108 dB
d:vote™ for Extreme SPL: Typ. 109 dB
Max. SPL, peak before clipping
d:vote™ for Loud SPL: 142 dB
d:vote™ for Extreme SPL: 152 dB
Output impedance
From MicroDot: 30 - 40 Ω
From DAD4099-BC/DAD6001-BC: 100 Ω
Cable drive capability
Up to 300 m (984 ft) with DAD4099-BC or DAD6001-BC XLR Adapter
Output balance principle
Signal balanced with DAD4099-BC or DAD6001-BC XLR Adapter
Common mode rejection ratio (CMRR)
> 60 dB from 50 Hz to 15 kHz with DAD4099-BC or DAD6001-BC XLR Adapter
Power supply (for full performance)
Min. 5 V – max. 50 V through DPA adapter for wireless systems
48 V phantom power ±4 V with DAD4099-BC or DAD6001-BC XLR Adapter
Current consumption
Typ. 1.5 mA (microphone)
3.5 mA with DAD4099-BC or DAD6001-BC XLR Adapter
Connector
MicroDot
Microphone length
45 mm (1.8 in)
Cable length / cable diameter
1.8 m (5.9 ft) / 1.6 mm (0.06 in) or 2.2 mm (0.09 in)
Gooseneck length
140 mm (5.5 in)
Capsule diameter
5.4 mm (0.21 in)
