Regulatory information
An example of this equipment has been tested and found to comply with the following European
and international Standards for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55022:2006
Immunity (EU): EN55024:1998
Electrical Safety (EU): IEC60065-01 + AMD1
Electrical safety (USA): UL60065-06
Mechanical installation
Important user information
Do not remove covers. No user serviceable parts inside, refer servicing to qualified service
personnel. For continued compliance with international EMC regulations, it is important that all
cables be screened, and connected as follows: Audio cable screens to their BLU-Device connector
ground. Control cable screens to the ground screws adjacent to the connector. Network cables
should be of type Cat 5, fitted with a clip-on ferrite sleeve (STEWART TYPE 28A2029-0A0) near
the network socket end. This equipment must be earthed. It should not be necessary to remove
any protective earth or signal cable shield connections to prevent ground loops. Any such
disconnections are outside the recommended practice of BSS Audio, and will render the EMC or
safety certificate void.
If the unit is likely to undergo extreme vibration through extensive road trucking and touring, the
unit must be supported at the rear and/or sides to lessen the stress on the front mounting flange.
Rear rack supports are provided to reduce stress on front mounting flange. Damage caused by
insufficient support is not covered by the warranty. To prevent cosmetic damage to the front panel
finish, use protective plastic cups under the rack mounting bolts.
124 312
2
4 143 3124 32 14 3
CONTROL
ETHERNET
LOCATE
OUTPUTS INPUTS
S + S + S + S +
S + S + S + S + S + S + S + S +S + S + S + S + S + S + S + S +
ABCDE
RS232
IN
OUT
BLU link
THIS EQUIPMENT MUST BE EARTHED
100-240V ~ 50/60Hz, 50W
MANUFACTURED IN
THE USA BY
BSS AUDIO
