19 EURODESK SX2442FX/SX3242FX User Manual
behringer.com
Main Outputs (¼")
Type ¼" TRS jack, electronically balanced
Impedance approx. 240 Ω balanced,
approx. 120 Ω unbalanced
Max. output level +28 dBu
Main Inserts
Type ¼" TRS jack, unbalanced
Max. input level +22 dBu
Mono Output
Type ¼" mono jack, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Low pass variable, 30 Hz to 200 Hz, 18 dB/oct.
Phones/CTRL Room Output
Type ¼" TRS jack, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
CD/Tape Out
Type RCA connector
Impedance approx. 1 kΩ
Max. output level +22 dBu
DSP
Type Texas Instruments
Converter 24-bit delta-sigma,
64/128-times oversampling
Sampling rate 46 kHz
Main Mix System Data
3
(Noise)
Main mix @ -∞, channel fader @ -∞ -100 dB / -102.5 dB A-weighted
Main mix @ 0 dB, channel fader @ -∞ -82 dB / -85 dB A-weighted
Main mix @ 0 dB, channel fader @ 0 dB -72 dB / -75 dB A-weighted
Power Supply
Power consumption 50 W
Fuse (100 - 240 V~, 50/60 Hz) T 2,0 A H 250 V
Mains connector Standard IEC receptacle
Physical/Weight
SX2442FX
Dimensions (H x W x D) 3.9 x 26.9 x 16.1"
100 x 682 x 410 mm
Weight (net) 19 lbs / 8.6 kg
SX3242FX
Dimensions (H x W x D) 3.9 x 35.3 x 16.1"
100 x 896 x 410 mm
Weight (net) 24.3 lbs / 11.0 kg
1
Equivalent Input Noise
2
Measuring conditions: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
3
20 Hz - 20 kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix;
channels 1/3 as far left as possible; channels 2/4 as far right as possible; reference = +6 dBu.
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
