![Behringer SX3242FX EURODESK [18/21] Specifications 7](/views2/2008135/page18/bg12.png)
behringer.com
18 EURODESK SX2442FX/SX3242FX User Manual
Specications7.
Mono Inputs
Microphone inputs (XENYX Mic preamp)
Type XLR connector, electronically
balanced, discrete input circuit
Mic E.I.N.
1
(20 Hz - 20 kHz)
@ 0 Ω source resistance -134 dB / 135.7 dB A-weighted
@ 50 Ω source resistance -131 dB / 133.3 dB A-weighted
@ 150 Ω source resistance -129 dB / 130.5 dB A-weighted
Frequency Response
<10 Hz - 160 kHz -1 dB
<10 Hz - 200 kHz -3 dB
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB GAIN
Impedance approx. 2.6 kΩ balanced
Signal-to-noise ratio 110 dB / 112 dB A-weighted
(0 dBu In @ +22 dB GAIN)
Distortion (THD + N) 0.005 % / 0.004 % A-weighted
Line Input
Type ¼" TRS jack,
electronically balanced
Impedance approx. 20 kΩ balanced,
approx. 10 kΩ unbalanced
Gain range -10 dB to +40 dB
Max. input level +22 dBu @ 0 dB GAIN
Fade-out attenuation
2
(Crosstalk attenuation)
Main fader closed 90 dB
Channel muted 84 dB
Channel fader muted 85 dB
Frequency response (Mic In → Main Out)
<10 Hz - 90 kHz +0 dB / -1 dB
<10 Hz - 160 kHz +0 dB / -3 dB
Stereo Inputs
Type 2 x ¼" TRS jack, balanced
Impedance approx. 20 kΩ balanced,
approx. 10 kΩ unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu @ 0 dB GAIN
CD/Tape In
Type RCA connector
Impedance approx. 10 kΩ
Max. input level +22 dBu
Equalizer
EQ mono channels
LOW 80 Hz / ±15 dB
MID 100 Hz to 8 kHz / ±15 dB
HIGH 12 kHz / ±15 dB
LOW CUT 80 Hz, 18 dB/oct.
EQ stereo channels
LOW 80 Hz / ±15 dB
LOW MID 500 Hz / ±15 dB
HIGH MID 3 kHz / ±15 dB
HIGH 12 kHz / ±15 dB
Channel Inserts
Type ¼" TRS jack, unbalanced
Max. input level +22 dBu
AUX/FX Send
Type ¼" mono jack, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
FX Returns
Type ¼" mono jack, unbalanced
Impedance approx. 10 kΩ
Max. input level +22 dBu
Subgroup Outputs
Type ¼" mono jack, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Main Outputs (XLR)
Type XLR connector,
electronically balanced
Impedance approx. 240 Ω balanced,
approx. 120 Ω unbalanced
Max. output level +28 dBu
