Dynacord IPX 10 8 [10/32] Scope of delivery
![Dynacord IPX 10 8 [10/32] Scope of delivery](/views2/2008286/page10/bga.png)
10 en | System overview
IPX Series DSP Multichannel Networking Power
Amplifier
2018.04 | 01 | F.01U.330.705 Installation manual Bosch Security Systems, Inc.
Keeping the cardboard box including all packing materials is also recommended, if the power
amplifier shows no external damages.
!
Caution!
Do not ship the power amp in any other but its original packaging.
When shipping the power amp, make sure to always use its original box and packaging
materials. Packing the power amplifier like it was packed by the manufacturer guarantees
optimum protection from transport damage.
3.4 Scope of delivery
IPX5:4, IPX10:4, and IPX20:4 components:
Quantity Component
1 IPX series DSP power amplifier
1 8-pin Euroblock-type connector, Output, 6 mm
2 6-pin Euroblock-type connector, Input
1 8-pin Euroblock-type connector, GPIO
4 M6x20 screw for rack mounting
1 Installation manual
1 Mains power connector, 32 A with safety & assembly instruction
1 Safety instruction booklet
IPX10:8 components:
Quantity Component
1 IPX series DSP power amplifier
2 8-pin Euroblock-type connector, Output, 6 mm
4 6-pin Euroblock-type connector, Input
1 8-pin Euroblock-type connector, GPIO
4 M6x20 screw for rack mounting
1 Installation manual
1 Mains power connector, 32 A with safety & assembly instruction
1 Safety instruction booklet
Keep the original invoice that states the purchase/delivery date in a safe place.
