Engineering Data Sheet
FX12-PRO
▪ Neodymium ND6 driver
▪ Neodymium ND12A mid transducer
▪ Extremely high sensitivity, 106 dB SPL 1W/1m
▪ Voice coil tracking protection
The FX12-PRO is a 12“ 2-way horn-loaded, coaxial, full-
range cabinet. The speaker is loaded with neodymium
high performance transducers from Electro-Voice, a
12” ND 12A woofer and a 1.4” compression driver.
Total nominal impedance is 8 Ohm. Total power
handling is 350 W RMS. Power amps up to 1200 W at
8 Ohm can be used in order to produce maximum
dynamic range without the danger of thermal overload
in non-controlled situations. Both drivers are
protected by a “Voice Coil Tracking” system called
protection circuitry which prevents overheating. The
dispersion angles of the horn are H 80° ✕ V 40°.
Extreme high sensitivity 106 dB/1 W/1 m; maximum
sound pressure level is 137 dB. Internal crossover
between mid and treble drivers 1000 Hz;
recommended crossover frequency to subwoofers
140 Hz, 18 dB/oct. Butterworth. Without subwoofers
this cabinet will provide excellent transmission of
speech on mid to long distances. The housing is made
of 15 mm birch plywood and coated with a very robust
textured paint. The front grille is made of powder
coated steel. 4 casters and 2 ergonomic handles
provide ease of handling. The cabinet features 6 flying
points. With the flying bracket FB-FX12-PRO it can be
easily hung on a truss and positioned to cover the
audience.
Parts included
Quantity Component
1 FX12-PRO
1 Engineering data sheet
1 Important safety instructions
Technical specifications
Description Passive mid-high speaker, coaxial
conical horn
Nominal impedance 8 Ω
Power handling
• Rated power RMS 350 W
• Program power 700 W
• Peak power 1400 W
Sound pressure level
• SPL 1 W/1 m 106 dB
• Maximum SPL (1 meter) 137 dB
Frequency range (-10 dB),
measured with Xa 4000
120–19000 Hz
