A.D.J. Supply Europe B.V. – www.americandj.eu – Focus Spot One User Manual Page 16

SYSTEM MENU (continued)

System Menu: System Menu: When making adjustments press ENTER to confirm your setup then press

and hold the MENU button for at least 3 seconds. To exit without making any adjustments press the

MENU button. The display will lock after 30 seconds, press the MENU button for 3 seconds to unlock

DMX Address - Set the DMX Address –

1. Press the MENU button until “DMX Addresss” is displayed, press ENTER.

2. “X” will now be displayed, “X” represents the displayed address. Press the UP or DOWN buttons to find

3. Press ENTER to confirm.

Slave Mode - This will let you set unit as a master or slave in a master/slave configuration.

1. Press the MENU button until “Slave Mode” is displayed, press ENTER. Either “Master”, “Slave 1” or “Slave 2”

will be displayed.

2. Press the UP or DOWN buttons until your desired setting is displayed, then press ENTER to confim.

Note In a Master/Slave configuration you can make one fixture the Master and then set the next fixture to “Slave

2”, the fixtures will now have contrast movement to each other.

Show Mode - Show modes 1 - 4 (Factory Shows).

1. Press the MENU button until “Show Mode” is displayed, press ENTER.

2. “Show X” will now be displayed, “X” representing a number between 0-4. Shows 1-4 are factory programs,

1 Press the MENU button until “Sound Sense” is displayed, press ENTER.

2. Press the UP or DOWN buttons to adjust the sensitivity level. The sensitivity level can be adjusted between

0 (the lowest) and 100 (most sensitive).

3. Press ENTER to set you desired level.

DMX Last State - This mode can be used as a precaution mode, that in case the DMX signal is

lost, the operating mode chosen in the setup is the running mode the fixture will go into when the DMX

signal is lost. You can also set this as the operating mode you would like the unit to return to when

power is applied.

1. Press the MENU button until “Last State” is displayed, press ENTER.

2 Either “Master Slave”, “Blackout”, or “Last State” will be displayed. Choose an operating mode you would like

3. Press ENTER to confirm your desired set up.

SYSTEM MENU (continued)
