FRONT PANEL FUNCTIONS
PRESENCE BASS MIDDLE
TREBLE HIGH TREBLE NORMAL
MAINS
ON ON
STANDBY
LOUDNESS 1 LOUDNESS 2
INPUTS
1
1
2
2
0
28
6
4
10 0
28
6
4
10 0
28
6
4
10
0
28
6
4
10 0
28
6
4
10 0
28
6
4
10
MK
II
1
1959SLP & 1987X FRONT PANEL
2 3 4 5 6
ENGLISH
1. MAINS
Mains power ON/OFF switch.
2. STANDBY
STANDBY is used in conjuncon
with the MAINS power switch (Front
Panel Funcon #1) to ‘warm up’ the
amplier before use and to prolong
the life of the output valves. When
powering up, always switch MAINS
power on rst, leaving the STANDBY
switch in the ‘standby’ posion. This
allows the applicaon of the voltage
required to heat the valves to their
correct operang temperature. Aer
approximately two minutes the valves
will have reached the correct operang
temperature and the amplier can be
engaged by switching MAINS power
ON.
Note: In order to prolong valve life, always
set the STANDBY switch to the ‘standby’
posion when turning the amplier sound
on and o during breaks in performance.
Also, upon full power down, always put the
amplier in ‘standby’ prior to switching o
the MAINS power.
3. INDICATOR
The power indicator will light when the
amplier’s mains power is switched on
and will be unlit when the mains power is
switched o.
4. PRESENCE
Controls the overall amount of higher
frequency content in your sound. Turn
clockwise to add crispness and bite for a
more cung tone. Presence is a power-
stage funcon and acts independently
of the preamp EQ controls.
5. BASS
Controls the amount of lower frequency
content, or boom-end, in your sound.
Turning clockwise will increase the
boom-end giving a fuller tone.
6. MIDDLE
Controls the middle frequency content
of your sound. Turning clockwise adds
girth. Turning anclockwise reduces
middle frequencies giving a smoother,
more ‘scooped’ tone.
7. TREBLE
Controls the high frequency content
of your sound. Turning clockwise will
increase the highs giving a brighter tone.
Tonal Note: The preamp EQ network
is dynamic and highly interacve, and
because of this altering the seng of one
II
