AKG D5 [11/14] Specifications

6 Specifications

AKG D 5/D 5 S

Polar pattern: supercardioid

Frequency range: 70 Hz to 20 kHz

Sensitivity: 2.6 mV/Pa (-52 dBV re 1 V/Pa)

Max. SPL for 1% / 3% THD: 147 / 156 dB SPL

Equivalent noise level: 18 dB(A) to DIN 45412

Impedance: ≤ 600 ohms

Re commended load impedance: ≥ 2000 ohms

Connector: 3-pin XLR

Finish: matte gray-blue

Size: length: 185.2 mm (7.3 in.);

diameter: 51 mm (2 in.)

Net weight: 340 g (12 oz.)

Shipping weight: 655 g (1.45 lbs.)

Patents: Varimotion varying-thickness diaphragm for

dynamic transducers (patents nos.

AT 403.751, US 6.185.809, DE 814.637,

DK 814.637, FI 814.637, FR 814.637,

GB 814.637, IT 814.637, NL 814.637)

This product conforms to the standards listed in the Declaration of Conformity.

To order a free copy of the Declaration of Conformity, visit http://www.akg.com

or contact sales@akg.com.

Frequency Response Polar Diagram
