parametertoOFF.ChangeswillbedisplayedonlywhenEQissettoON.

EQTYPE:possiblecommands:GET,SET.Youhavetospecifytheequalizerbandfrom1to4.

PossiblevaluesareOFF,HPF,LOSHELF,PEAK,HISHELF,LPF.Acommandcouldlooklikethis:

“GETEQTYPE3”.Theunitwillreply:“EQTYPE3PEAK”indicatingthatthethirdbandofthe

equalizerisapeakingtypeequalizer.

EQFREQ:possiblecommands:GET,SET.Youhavetospecifytheequalizerbandfrom1to

4.Possiblevaluesarefrom10to20000.Aninstructioncouldlooklikethis:“SETEQFREQ2

1000”,indicatingthatyouwanttosettheequalizercenterfrequencyofequalizerband2to

1000Hz.Theunitwillreply:“EQFREQ21000”ifthefrequencyischangedandVALFBisON.

EQGAIN:possiblecommands:GET,SET.Youhavetospecifytheequalizerbandfrom1to4.

Possiblevaluesarefrom-12to12(dB)in0.1dBsteps.Aninstructioncouldlooklikethis:“SET

EQGAIN23.5”indicatingthatyouwanttosettheequalizergainofequalizerband2to3.5dB.

Theunitwillreply:“EQGAIN23.5”.

EQQFACTOR:possiblecommands:GET,SET.Youhavetospecifytheequalizerbandfrom1to

4.Possiblevaluesare0.08,0.12,0.18,0.25,0.35,0.50,0.71,1.00,1.41,2.00,2.83,4.00,

5.66,8.00,11.3,16.0.Acommandcouldlooklikethis:“SETEQQFACTOR32.00”.Theunit

willreply“EQQFACTOR32.00”

DELAY:possiblecommands:GET,SET.Youhavetospecifythechannel:LEFT,RIGHTorALLfor

bothandalsothevaluebetween0.0and6.0in0.1metersteps.Aninstructioncouldlooklike

this:“SETDELAYRIGHT2”.Theunitwillreply:“DELAYRIGHT2.0”

AUTOLD:possiblecommands:GET,SET.BinaryvaluesareON,OFF.WhenAUTOLDisON,

agentleboostoflowandhighfrequencieswillbeappliedtotheaudiosignalonlowvolume

settings.Athighvolumesettings,theeffectisgraduallyswitchedoff.

EXTVOL:possiblecommands:GET,SET.BinaryvaluesareON,OFF.Usethisparameterto

enableordisabletheexternalvolumecontroloption.Pleasenotethatenablingtheexternal

volumewillalwaysdisablethevolumecontrolfunctionusingthefrontdial!Whentheunitis

locked,itwillstillbepossibletocontrolthevolumeviatheexternalvolumecontrol,however,the

maximumsetmasterlevelwillalwaysberespected.Externalvolumecontrolwillalwaysbein2

dBsteps,whereasfrontdialvolumecontrolispossiblein1dBsteps.Thisisnotamalfunction!

LOCKMD:possiblecommands:GET,SET.PossiblevaluesareLOCKED,UNLOCKED,

VOL_ONLY.SupposeyouwanttolockthefrontpaneloperationviaanRS232command,in

thiscasethecommandlookslikethis:“SETLOCKMDLOCKED”.Thepasswordtounlockthe

unitcanbechangedonlyviathefrontpanelcontrols,notviaRS232.Thismeansthatanyuser

capableofcommunicatingwiththisunitisabletounlockthefrontpanelcontrolsusingRS232

commands.However,theRS232commandscanbelocked.Theprocedureisdescribedbelow,

see“RS232LOCK”.
