Involight LED MH100 [12/12] Appendix

LEDMH100 MOVING HEAD

To ensure the best effect of lamp, please clean every lean or reflective setting. Use the

soft cotton with some lotion to clean it, but do not damage lens.

Third, check line during a certain time.

Check connecting line, wiring and ground line to ensure safety of using lamp during a

certain time.

Forth, mechanical transmission part maintenance.

Check mechanical transmission part if it has any loose part during a certain time, such as

a strap. Abrasion of mechanical transmission part will affect stability of lamp work. If strap

is loose, you should change it if needed.

TECHNICAL SPECIFICATION

Type-------------------------------------------------------------LEDMH100 MINI LED MOVING-HEAD

LED Number& Voltage------------------------------------------------------------------------36X1W LED

Power------------------------------------------------------------------------------------------------------160W

Voltage-----------------------------------------------------------------------------------------------------220V

Electrical current------------------------------------------------------------------------------------0.7 2 6 A

Total lumens---------------------------------------------------------------------------------------528.15 1m

Max light intensity-------------------------------------------------------------------------------1089 c d

Lamp efficiency----------------------------------------------------------------------------------3.8 lm/w

Optic angle -----------------------------------------------------------------------------------------------23

Dimension-----------------------------------------------------------------------L250XW220XH376 (MM)

Weight------------------------------------------------------------------------------------------------------ 7KG

APPENDIX

Color Total output (Lumens) Efficiency Color index

Red 465 5 21

Green 528 4 -12

Blue 788 5 -50
