LEDMH100 MOVING HEAD
7
Pr1-4 means skip
Pr5-8 means fade
SPCO SP01~15 Auto speed SP01: 0.1sec/step, SP15: 10secs/step
r PAN STND Run clockwise as DMX value increases
REV Run anticlockwise as DMX value decreases
R TILT STND Run clockwise as DMX data increase
REV Run anticlockwise as DMX data decreases
r-PT STND CH7: PAN, CH8: TILT, CH10: PAN FINE, CH11: TILT FINE.
REV CH7: PAN, CH8: TILT, CH10: PAN FINE, CH11: TILT FINE.
TEST ALL Check all channels with motors
PAN Check pan channels
TITL Check tilt channels
RED Check red channels
GREEN Check green channels
BLUE Check blue channels
DISP STND Display bites normally
REV Display bytes upside down
REST REST/ON Reset
(Press ENTER button to enter into REST menu and the screen
reads flashing “REST”. Then press UP/DOWN button and the
screen reads flashing “ON”. If to press ENTER again, the light
engine resets again)
16BT
ON PAN, TILT is 16 bit, CH10: PAN FINE, CH11: TILT FINE.
OFF PAN, TILT is 8 bit. CH10, CH11 does not exist.
4. ABOUT EACH CHANNEL
■ Channel 1:DMX MODE
Ch DMX Function CH2 CH3 CH4 CH5 CH6
CH1
0~24 RGB
Red
0~255
Green
0~255
Blue
0~255
Strobe
Speed
0~255
Dimme
r
0~255
25~49
Built-in program
1
No
function
No
function
No
function
Auto
speed
No
functio
n
50~74
Built-in program
2
75~99
Built-in program
3
