11. System functions: Extern menu Nord Stage EX v6.x
Page 70
EXTERN MENU
Press SHIFT + EXTERN to access the Extern menu, where you can find settings and functions relating
to the Extern section - see “The Extern section” on page 63. Use the P
AGE -/+ buttons to navigate
between the various menu items on the menu. The V
ALUE DIAL is used to change settings. When you
are done, press E
XIT (SHIFT) briefly to exit the menu.
Most items on the Extern menu have separate entries for Panel A and B! Most settings from the Ex-
tern menu are saved with a Program. The only exceptions are the “Extern MIDI A/B Channel” if Ex-
tern MIDI Mode is set to Global, and “Send on Load”.
The following items can be found on the Extern menu:
Function Description Range/Values
Extern MIDI
Mode
The Extern MIDI Channel can be determined in two different
ways, globally, or independently for each program. When “Glo-
bal” is selected, the Extern MIDI A & B channels will be the same
for all programs. If Program is selected, the Extern MIDI A & B
channel will be saved with each Stage EX program.
Global, Program
Extern MIDI A/B
Channel
This sets the MIDI channel the Extern section should use . 1-16 (14 default for
Panel A, 15 is
default for Panel B)
Extern MIDI A/B
Volume
The Extern section can send MIDI Volume messages (0-127),
allowing you to control the level of the external device.
Off (Default), 0-127
Extern MIDI A/B
Prog Change
The Extern section can transmit MIDI Program Change mes-
sages (0-127), allowing you to change programs on external
devices.
Off (Default), 1-128
Extern MIDI A/B
Bank Sel cc00
This allows you to set a value for a MIDI Bank Select message
on Control Change address 00 (cc00).
Off, 0-127
Extern MIDI A/B
Bank Sel cc32
This allows you to set a value for a MIDI Bank Select message
on Control Change address 32 (cc32).
Note that there are many different variations between instru-
ments in how Banks are numbered and accessed via MIDI.
Off (Default), 0-127
Extern MIDI A/B
CC Value
This will transmit values for the selected MIDI CC number. Off (Default), 1-127
Extern MIDI A/B
CC Number
This decides which MIDI Controller number the Extern section
should be transmitted when MIDI CC is activated.
MIDI CC 0-119
(Default is 2)
Extern MIDI A/B
Send Wheel
To avoid transmitting Modulation Wheel messages make sure
this option is set to “No”.
Yes (Default), No
Extern MIDI A/B
Send A.Touch
To avoid transmitting After Touch messages make sure this
option is set to “No”.
Yes (Default), No
Extern MIDI A/B
Send CtrlPed
To avoid transmitting Expression Pedal messages make sure
this option is set to “No”.
Yes (Default), No
Extern MIDI A/B
Vel Curve
Use this setting to adjust the velocity response curves in the
Extern section.
Norm (Default),
Soft, Hard
Extern MIDI
Send on Load
To avoid transmitting Program Change, Volume or MIDI CC mes-
sages when you load a Program in Nord Stage EX, make sure
“Send On Load” is set to “Off” on the Extern menu.
No (Default), Yes
