Nord Stage EX v6.x 13. Nord Sound Manager: Nord Sound Manager reference
Page 83
SELECT ALL (CTRL+A)
Select all items in a bank.
I
NVERT SELECTION
This will deselect the original selection(s) and then select all the other items in the list.
VIEW
ORGANIZE (CTRL+O)
When this option is checked, the lists will show all the available locations in the selected partition/
bank and not only the occupied ones. This will for instance make it easier to drag a file to a specific
free location in the middle of the list. If this is unchecked, only the occupied locations will be
shown.
D
UAL VIEW (CTRL+L)
Select this option if you need to move items between different banks. Please note that both lists rep-
resent the actual memory content in the Nord Stage. Any actions that you make in either of the lists
will affect the memory content in the Stage.
A
UTO SELECT
When this function is active, programs will be automatically selected in the Nord Stage EX when you
browse through the Programs in the Manager list, with the computer keyboard arrow keys.
HELP
ABOUT
Brings up the About box with a information regarding the version of the Nord Sound Manager. You
will also see a list of compatible instruments and OS versions..
