14  |   Nord PiaNo 2 User MaNUal os v1.1X
Master level
This control sets the overall output level of
the Nord Piano 2, at the L/R and the head-
phone outputs.
M This is not a programmable control.
MIDI Indicator
The MIDI indicator below the Master Level is a LED that flashes when
MIDI data is received. Short flashes indicate any incoming MIDI, longer
flashes indicates accepted MIDI data (on the correct MIDI channel etc.).
Program section
This is the section where you select the banks and programs, where
the Store functions are activated and where you enter the System,
MIDI, Sound and Pedal menus to change these settings.
Up/Down buttons
The Up/Down buttons to the left of the display have several functions
in the Nord Piano 2. Press repeatedly to select one of the 24 Pages in
each Bank; the Bank, Page and Program number and the name of the
program will be presented in the display.
Bank selection
Hold Shift and press Up or Down to select Bank A or Bank B.
Menus
If you have entered any of the System, MIDI, Sound or Pedal menu,
these buttons are first used to select a menu function, and then to-
gether with the Shift button to change the value of a selected function.
Read more about the menus on page 19.
Display
The LCD will show the active program location and the name of the
program. If you edit a program, an asterisk will appear next to the
program number, at the upper row of the display.
If you have entered any of the menus, the setting for each menu item is
shown in the LCD.
The LCD will also display values and settings when you change any of
the functions on the panel. Press and hold Shift while turning a knob to
display the value without changing it.
Store
The red Store button is used when you want
to store the settings that you have made, in
Programs.
1 Press the Store button once and the Store
LED will start to flash.
The display will ask you for a location where to store your new
program - the first option is at the original location.
2 Select the desired location with the Up/Down and the Program
1-5 buttons. Skip this step if you want to overwrite the original.
When you select a new location, the name of the program cur-
rently in the destination will be displayed and the settings will also
become active on the Nord Piano 2. This allows you to verify that
you will not overwrite something important.
3 Press Store again to confirm your intentions and to store the cur-
rent settings to the selected location.
If you change your mind, press any button except the Up/Down or
the Program buttons on the Nord Piano 2 panel to abort the store
procedure.
Store As...
Use the Store As feature when you want to store a program with
another name.
1 Press Shift + Store.
The display will show “Set Name” and the current name of the
program on the lower row.
2 Use the Up/Down buttons to select the position, press and hold
Shift and use the Up/Down buttons to select the character.
The display can show 11 characters of a program name.
3 Confirm your intentions by pressing Store once more.
This procedure may be aborted by pressing the Shift button.
M In order to be able to store settings the Memory Protection must
be turned off. Read more about this on page 11.
6 
Nord Piano 2 Reference
