Program & Controller dumps
To dump a Program Sys Ex, or MIDI Controller data via MIDI, either
to another Nord Piano 2 or for recording the data into another MIDI
device, proceed as follows:
Sending program dumps
1 Connect the MIDI Out on the Nord Piano 2 to the MIDI In on the
receiving device (or use the USB capabilities).
2 Set up the receiving device to accept MIDI Sys Ex and MIDI
Controller data.
3 Press Shift + MIDI and select the “Dump One” or “Dump All” menu
item using the Up/Down buttons.
4 If needed, set the receiving MIDI device to “recording mode”.
5 Press the Store button to send the dump to the MIDI Out of Nord
Piano 2. The display will inform you when the transmission has
been completed.
M All program parameters will be sent but NOT the actual piano or
sample sounds.
When dumping back a program that uses a piano sound, make sure
the actual piano are also available in the Nord Piano 2. Otherwise the
parameters in the Sys Ex message will be applied to another available
piano instrument.
Sending MIDI Controller dumps
1 Set up as in steps 1 and 2 in the preceding description.
2 Press Shift + MIDI and select the “Send CC” menu item using the
Up/Down buttons.
3 Press the Store button to send the dump to the MIDI Out of Nord
Piano 2. The display will inform you when the transmission has
been completed.
Receive MIDI SysEx dumps
Here is how to receive a MIDI SysEx Dump:
1 Connect the MIDI Out on the transmitting device to the MIDI IN on
the Nord Piano 2.
2 Initiate the transmission on the transmitting device.
If the dump contained all Programs (All), it will replace all programs cur-
rently stored in the Nord Piano 2. If the dump contained only a single
program, it will be temporarily placed in the currently selected program
memory location.
An asterisk will appear in the display to in the upper, left area next to
the program number to indicate an unsaved edit. You then have to
store the program manually to a memory location using the Store func-
tion (see page 14).
MIDI Controller list
These are the MIDI Controller numbers used for all the knobs and the
buttons on the Nord Piano 2 front panel:
Nord Piano 2 Parameter
MIDI
Controller
Kbd Split 14
Transpose 15
Kbd Touch 33
Sustped Off 34
Piano Level 106
Piano Type 12
Piano Model 44
Piano On/Off 46
Clav Model 45
Acoustic Model String Resonance/Release 79
Acoustic Model Pedal Noise 78
Piano Octave Shift 105
Synth Level 51
Sample Select 52
Synth Attack 53
Synth Release 54
Synth On/Off 55
Synth Octave Shift 56
Effect 1 Rate 63
Effect 1 Type 60
Effect 1 On/Off 69
Effect 1 Source 70
Effect 2 Rate 62
Effect 2 Type 61
Effect 2 On/Off 80
Effect 2 Source 71
Delay Mix 75
Delay Feedback 76
Delay On/Off 84
Delay Source 85
EQ On/Off 115
EQ Treble 113
EQ Mid 116
EQ Mid Freq 117
EQ Bass 112
EQ Source 118
Amp/Comp On/Off 86
Amp/Comp Amount 111
Amp/Comp Sel 81
Amp/Comp Source 87
Reverb Wet/Dry 102
Reverb Sel 96
Reverb On/Off 97
Sustain pedal 64
Soft pedal 67
Sostenuto pedal 66
Volume Pedal 11
ChaPter 9 Midi | 23
