Dump Program One, All
This allows you to perform a MIDI Sys Ex dump of the currently se-
lected Program or of all the programs in the Nord Piano 2. Press the
Store button to perform the transmission.
In the MIDI chapter on page 23 is a description on how the Nord
Piano 2 receives a Sys Ex dump.
Sound Menu
Piano Pedal Noise level
Sets the level of the Pedal Noise that can be turned on for selected
pianos.
Range: +/- 6 dB (0 dB default)
Piano String Res Level
Sets the level of the String Resonance feature that can be turned on for
selected acoustic pianos.
Range: +/- 6 dB (0 dB default)
FX Delay Mode
This sets if the delay should change the pitch on sounding repeats in
the fashion of an analog delay, if the Tempo is adjusted with the Up/
Down buttons. When set to Normal, the pitch does not change if the
Rate/Tempo is changed with the buttons.
Range: Analog (Default), Normal.
Pedal Menu
Piano Pedal
Select the functionality of the sustain pedal you have attached to the
Nord Piano 2. The default Auto setting tries to determine what type of
pedal you have connected.
If you have a switch pedal type of another brand (Roland DP-2, DP-6,
Yamaha FC-4, M-Audio etc.), select the Sw.Open or Sw.Close option,
depending on the polarity of the pedal.
Type: Auto (default), Triple, Closed, Open
Volume Pedal Type
Select the type of the pedal you have attached to the Volume Pedal
input on the Nord Piano 2. The range of a connected pedal will be
shown in the display if you operate the pedal. This can help you match
the performance of a pedal that isn’t directly available in this menu.
Type: Roland EV5 (default), Roland EV7, Yamaha FC7, Korg, Fatar
SL
Volume Pedal Gain
This setting allows you to add some gain to the output of the pedal.
This can be used if an attached pedal does not reach the maximum
level or setting.
Range: 1 - 10
Volume Pedal Func
Select the destination of the pedal you have attached to the Volume
Pedal input on the Nord Piano 2.
You can use a pedal to control the volume of the entire instrument or
just the Sample Synth, to be able to fade in for example strings or pads
on top of the pianos.
Func: Volume (default), Syn Volume
Sostenuto Pedal Func
If you have the extra accessory, the Nord Triple Pedal, the middle pedal
of the three is the sostenuto pedal. This pedal can be set to three dif-
ferent functionalities, Sostenuto, Syn Sustain and SynSustGate.
Sostenuto will only sustain those keys that were held down when this
pedal was pressed down.
The Syn Sustain mode allows you to have separate control of the
sustain for the Sample Synth and the Pianos.
The SynSustGate mode will allow the middle pedal to sustain the synth
and also remove any keyboard information, making it possible to latch
notes played by the Sample Synth, while still being able to continue to
perform with the Piano (and the normal sustain pedal).
E If a switch-type pedal is used instead of a Nord Triple Pedal, the
Sample Synth sustain functionality will revert to the sustain pedal.
Func: Sostenuto (default), Syn Sustain, SynSustGate
20 | nord piano 2 user Manual os v1.1X
