XD-V35 Digital Wireless System Specifications
System
Frequency Band 2.4GHz ISM Band
Compatible Channels 6
Spatial Diversity with Digital Buffering Yes
Frequency Diversity Yes (2 Frequencies per channel)
Compander-Free Design Yes
Frequency Response THD % 10 Hz (-0.5 dB) - 20kHz (-2.5 dB)
0.03% typical
System Latency < 3.5 ms (audio input to output)
Operating Temp Range 0 – 50 degrees C
Range up to 275 feet (83 meters)
Actual range will depend on nearby RF interference sources including line of sight
obstacles
Receiver
RF Signal Strength Indicator
Battery Level Indicator
3-Segment LED
3-Segment LED
Audio Presence LED Yes
Squelch & Pad adjustments None required
Receiver Antennas Internal
Receiver Format Table Top
Receiver Power Requirements 9Vdc 200mA
Output Impedance XLR: 150 Ohms
Balanced / 1/4”: 1 kOhm Unbalanced
95 dBm
Sensitivity Image Rejection 56 dB
Transmitters
Transmitter RF Output Power 10 mW
Battery Life 8 hours
Batteries 2 x AA Alkaline
Battery Level Display Low Battery LED
Dynamic Range
THH06 Handheld
TBP06 Beltpack
>115 dB
>118 dB
TBP06 Maximum Audio Input Level 6.5 Vpp
TBP06 Beltpack Input Impedance 1.3 M Ohms
TBP06 Beltpack Supplied Bias Voltage 5 VDC
Pinout To TBP06 Beltpack 1/4” TRS Connector
•Tip = Signal
•Ring = Bias Voltage, 5 VDC
•Sleeve = Ground
