LINE 6 StageSource L2m [10/20] L2 t l2m

L2t / L2m Back paneL

10. Line Input – Connecttheline-leveloutputofyourmixertothecombi(XLRor1/4-inch)Lineinput.The1/4-inchinputcanacceptunbalanced

(Tip-Sleeve)orbalanced(Tip-Ring-Sleeve)cables.TheSignalLEDlightsgreenwhenasignalispresentandmayashrediftheinputisclipped.

11. L&R Aux Inputs – TheseL&RstereoRCAjacksareforconnectingtheaudiooutputofaDJmixer,MP3player,orCD/DVDplayer.Whenusinga

singleL2t/L2mspeaker,theleftandrightinputsaresummedtomono.IfasecondL2torL2misconnectedviaL6LINK,theleftandrightAuxInputs

will be automatically split between the two speakers.

12. Feedback Suppression – Turnsonthe12-bandfeedbacksuppressioncircuitfortheMixerInputchannel.PresstheOnbuttontoenableor

disableFeedbackSuppression;pressandholdtheOnbuttontoselectaggressive(red),medium(amber),ormild(green)FeedbackSuppression.

13. Loop Thru Output – ThisoutputduplicatesthesignalreceivedattheLineinputjack.

14. Mix Out Output – This output sends a mix of all three channels (Channel 1, Channel 2, and back panel inputs)

15. Master Level – Setstheoveralloutputlevel.TheLimitLEDlightsiftheMasterLimiterkicksin.

16. Speaker Mode – L2t/L2mcanbeoptimizedforvariousapplications.PresstheSpeakerModebuttontocyclebetweenReference/P.A.,Playback,

FloorMonitor,Keyboards,AcousticGuitar,orElectricGuitar.Seethetablebelowformoreinformation.

17. L6 LINK

– Thisconnectionprovidesapowerful,proprietarydigitallinkbetweenvariousL6LINK-compatibleproducts,enablingeasy,reliable,

one-cableconnectivity.InthecaseofL2t/L2m,L6LINK-connectedspeakerscanbedaisy-chained,allowingallproductstosyncandcommunicate

uniquelywitheachother.WhentwoormoreL2torL2mspeakersareconnectedviaL6LINK,the7-segmentdisplayindicateswhethereachspeaker

isleft(“L”),right(“r”),orL+Rmono(“b”).WhenusedwithaStageScapemixer,the7-segmentdisplayidentieseachspeakerwithanumber.

18. Power Switch – Turns the speaker on and off.

Speaker Mode Description

Reference/P.A. Thisistherecommendedmodeforlivesoundreinforcement,withaatfrequencyresponse,a2.2kHzcrossoverfrequency,

and maximum low frequency extension.

Playback Optimizedforprerecordedmusic;similartoP.A.modewithanemphasisatextremelowandhighfrequencies.

FloorMonitor SimilartoP.A.modewithaslightreductioninlowfrequencycontenttocounteractcouplingwhenplacingthespeaker

ontheoor.Ifthespeakerispoweredonwhileinahorizontalposition,FloorMonitorspeakermodewillbeselected

automatically. The user can then change to a different mode, if desired.

Keyboards Flatfrequencyresponsewitha3.5kHzcrossoverfrequency;providesawarmerresponsethat’sbetterforinstruments,and

adds more relative energy from the cone.

AcousticGuitar 3.5kHzcrossoverfrequency,withatailoredlow-frequencyresponsetominimizeboominess.

ElectricGuitar Theoverallfrequencyresponseemulatesthesoundofa212comboamp.The10”speakerplaysfullrange,withthehorn

adding only the smallest amount of sparkle.
