7
A Power switch (STANDBY/ON)
B MASTER VOLUME dial
This determines the overall volume of the
PortaTone.
C OVERALL buttons
(s, t, +, -)
These are for selecting the various “overall”
functions and setting their values. (See page 23.)
D SONG button
This selects the Song mode. (See page 20.)
5 STYLE button
This selects the Style mode. (See page 28.)
6 VOICE button
This selects the Voice mode. (See page 15.)
G Numeric keypad, +/- buttons
These are for selecting songs, voices, and styles.
(See page 16.) They are also used for entering
certain values, such as the time signature for the
Metronome (page 14), and the key signature for
the Smart Chord function (page 38).
H ACMP ON/OFF button
When the Style mode is selected, this turns the
auto accompaniment on and off. (See page 31.)
This button has no function in the Song mode.
I SYNC-START, Pause (❙❙) button
When the Style mode is selected, this turns the
Sync-Start function on and off. (See page 29.)
When the Song mode is selected, this alternately
pauses and starts song playback. (See page 24.)
J START/STOP (>/■) button
When the Style mode is selected, this alternately
starts and stops the auto accompaniment. (See
page 29.) When the Song mode is selected, this
alternately starts and stops song playback. (See
page 24.)
K INTRO/ENDING, button
When the Style mode is selected, this is used to
control the Intro and Ending functions. (See
pages 29, 30.) When the Song mode is selected,
this is used to control the A/B Repeat function.
(See page 24.)
L MAIN A/B (AUTO FILL), Fast Forward
(f)/Rewind (r) buttons
When the Style mode is selected, these are used to
change auto accompaniment sections and control
the Auto Fill function. (See page 32.) When the
Song mode is selected, these are used to respec-
tively fast forward and rewind during song play-
back. When Song playback is stopped, they can be
used to advance or reverse to specific measure
numbers in the song. (See page 24.)
M OTS, VOICE CHANGE button
When the Style mode is selected, this is used to
turn the One Touch Setting (OTS) function on and
off. (See page 36.) When the Song mode is
selected, this is used to turn the Voice Change
function on and off. (See page 27.)
N CHORD GUIDE, MELODY GUIDE button
When the Style mode is selected, this is used to
control the Chord Guide functions. (See page 37.)
When the Song mode is selected, this is used to
control the Melody Guide function. (See page
26.)
O PORTABLE GRAND button
This instantly changes to the Voice mode and calls
up the Grand Piano voice. (See page 13.)
P METRONOME button
This turns the metronome on and off. (See page
13.)
Q MULTI PAD buttons
These are used to automatically play pre-pro-
grammed musical phrases. (See page 40.)
R DEMO button
This is used to play the Demo songs. (See page 11.)
S TOUCH button
This turns the Touch Response function on and off.
It also lets you set the Touch Sensitivity setting.
(See page 19.)
Panel Controls and Terminals
5
