1. INTRODUCTION
Amari is a hi-end 384kHz PCM / DSD256 AD/DA converter. Its majestic sound will
suit mixing engineers, mastering gurus and the most dedicated audiophiles. The
beautifully designed desktop unit is equipped with a slick touchscreen display. It
offers 1 pair of Analog outs (either on XLR or TRS connectors), 1 pair of analog in-
puts (either on Combo XLR or RCA, and 2 high power headphone HP outputs with
dedicated volume control and adjustable output impedance.
KEY FEATURES:
High-End 24bit 384 kHz AD 2x AK5578 and DA 8x CS43198 converters
resulting in dynamic range of 128dB for the A/D and 138dB for the D/A
DSD64, DSD128 and DSD256 formats supported DSD over PCM
2 headphone outputs with dedicated volume control for each output with
user-selectable output resistance (a.k.a. headphone membrane weight com-
pensation) that can be switched to balanced mode.
1 pair of analog outputs (either on XLR or TRS
1 pair of analog inputs (either on combo XLR or RCA
Large touchscreen display to ease the advanced functions control and visu-
alization
Dedicated knobs and buttons for fast access of the most frequent controls
Stunning design
10M and WC input for better system integration and improved audio clarity
Convenient and easy to use control panel on PC/MAC
2. SAFETY NOTES
To reduce the risk of electrical shocks, fire, and related hazards:
1. Do not remove the screws, cover, or cabinet. There are no user-serviceable parts
inside.
2. Refer servicing to qualified service personnel.
3. Do not expose this device to rain, moisture or spillover of liquid of any kind.
4. Should any form of liquid or a foreign object enter the device, do not use it.
Switch off the device and then unplug it from the power source. Do not operate the
device again until the foreign object is removed or the liquid has completely dried
and its residues fully cleaned up. If in doubt, please consult the manufacturer.
