Dynacord A 115 Руководство по эксплуатации онлайн
Features:
• DH-1K 1.5-inch Titanium Diaphragm Compres-
sion Driver
• EVS-15K 15-inch Woofer
• 97 dB SPL sensitivity, 129 dB max. SPL
• 400 W continuous, 1600 W peak power
• 15 mm Plywood Enclosure
Engineering Data Sheet
A 115
15-inch two-way full-range cabinet, passive
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for “flying”
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Order No. A115: F01U270186
Cabinet Full Range
Nominal impedance 8 Ohms
Minimum impedance 7.4 Ohms
Power Handling
continuous 400 W
program 800 W
peak 1600 W
Max. SPL (calculated with peak
power)
129 dB
Axial Sensitivity 97 dB
Frequency Range (-10 dB) 55 Hz to 20 kHz
Frequency Response (-3 dB) 75 Hz to 18 kHz
Recommended HP Frequency 40 Hz
Coverage (Horizontal x Vertical) 90° x 50°
LF Transducer 1 x EVS-15K, 381 mm (15“),
F01U250940
HF Transducer DH-1K, 39 mm (1.5“), Titanium Dia-
phragm Compression Driver,
F01U250928
Crossover Frequency 2.1 kHz
Connectors 2 x NL4-type
Enclosure Material 9-ply, 15 mm Plywood, internally braced,
with textured paint
Grille 18-GA Steel with black powdercoat
Handles 2
Product Dimensions (H x W x D) 708 x 432 x 382 mm
Shipping Dimensions (H x W x D) 785 x 500 x 450 mm
Net Weight 21.9 kg
Shipping Weight 27.1 kg
Warranty 5 years
Optional Accessories
VPM 1500, variable speaker pole F01U141047
BS 35, speaker stand F01U141046
SH-A115, Dust Cover F01U270396
Recommended extensions
A 118 Subwoofer F01U270187
