Behringer VMX1000USB PRO MIXER [10/13] Specifications especificaciones técnicas

behringer.com

18 PRO MIXER SERIES VMX100USB/VMX200USB/VMX300USB/VMX1000USB

behringer.com

19Quick Start Guide

Specications Especicaciones técnicas

VMX100USB VMX200USB VMX300USB VMX1000USB

AUDIO INPUTS

Mic In ¼" TRS, 53 dB gain ¼" TRS, 40 dB gain ¼" TRS, 46 dB gain Balanced XLR, 40 dB gain

Phono In Unbalanced RCA, 40 dB gain

Line In Unbalanced RCA, 0 dB gain

Return — Unbalanced RCA, 0 dB gain Unbalanced RCA, 0 dB gain Unbalanced RCA, 0 dB gain

Mic Aux Return — — — ¼" unbalanced, 3 dB gain

AUDIO OUTPUTS

Main Out (A) max. +21 dBu @ +15 dBu (line in) max. +21 dBu @ +10 dBu (line in) max. +21 dBu @ +5 dBu (line in) max. 25 dBu, balanced XLR

Main Out B — — — max. 21 dBu, unbalanced

Booth — — max. +13 dBu —

Tape Out typically 0 dBu

Send — typically 0 dBu — —

Mic Aux Send — — — -∞ to +6 dBu

Phones Out typically 125 mW @ 1% THD typically 125 mW @ 1% THD typically 125 mW @ 1% THD max. 180 mW @ 75 Ω

SUBWOOFER

Subwoofer Out — — — Balanced XLR

X-Over — — — Variable 30 - 200 Hz

Level — — — -∞ to 0 dBu @ 0 dB input

EQUALIZER

Stereo Low +12 dB/-32 dB @ 50 Hz

Stereo Mid — +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz

Stereo High +12 dB/-32 dB @ 10 kHz

Mic Low — +12/-12 dB @ 50 Hz +12/-12 dB @ 50 Hz +15/-15 dB @ 80 Hz

Mic Mid — — — +15/-15 dB @ 2.5 kHz

Mic High — +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz

Kill Low — — -54 dB @ 50 Hz —

Kill Mid — — -44 dB @ 1 kHz —

Kill High — — -26 dB @ 10 kHz —

USB

Audio Stereo In/Out

Connector Type B

Converter 16-bit

Sample rate 48 kHz

SYSTEM SPECIFICATIONS

Signal-to-noise ratio >88 dB (line) >86 dB (line) >85 dB (line) >80 dB (line)

Crosstalk >67 dB (line) >77 dB (line) >77 dB (line) <-70 dB (line)

Distortion (THD) <0.025% <0.06% <0.05% <0.05%

Frequency response 20 Hz - 20 kHz

Input gain adjustment -20 dB - +9 dB

POWER SUPPLY

Mains voltage

USA/Canada 120 V~, 60 Hz

UK/EU/SAA/CCC 230 V~,50 Hz

Japan 100 V~, 50-60 Hz

Power consumption max. 10 W max. 13 W max. 22 W 22 W

Fuse

100-120 V~: T 160 mA L 250 V

220-230 V~: T 80 mA L 250 V

100-120 V~: T 400 mA L 250 V

220-230 V~: T 250 mA L 250 V

100-120 V~: T 500 mA L 250 V

220-230 V~: T 315 mA L 250 V

100-120 V~: T 500 mA H 250 V

220-230 V~: T 250 mA H 250 V

Mains connection Standard IEC receptacle

DIMENSIONS/WEIGHT

Dimensions (H x W x D)

2 ⁄ x 8 x 9"

72 x 203 x 229 mm

3 ½ x 8 x 11"

88 x 203 x 280 mm

3 ½ x 9 ½ x 13 ⁄"

88 x 241 x 332 mm

4 ⁄ x 19 x 8 ¾"

107 x 483 x 223 mm

Weight 4.4 lbs / 2 kg 5.5 lbs / 2.5 kg 7.3 lbs / 3.5 kg 7.9 lbs / 3.6 kg

VMX100USB VMX200USB VMX300USB VMX1000USB

ENTRADAS AUDIO

Entrada Micro TRS 6,3 mm, 53 dB ganancia TRS 6,3 mm, 40 dB ganancia TRS 6,3 mm, 46 dB ganancia XLR balanceado, 40 dB ganancia

Entrada Giradiscos RCA no balanceado, 40 dB ganancia

Entrada de Línea RCA no balanceado, 0 dB ganancia

Retorno — RCA no balanceado, 0 dB ganancia RCA no balanceado, 0 dB ganancia RCA no balanceado, 0 dB ganancia

Retorno Micro Aux — — —

6,3 mm no balanceado,

3 dB ganancia

SALIDAS AUDIO

Salida principal A máx. +21 dBu @ +15 dBu (line in) máx. +21 dBu @ +10 dBu (line in) máx. +21 dBu @ +5 dBu (line in) máx. 25 dBu, XLR balanceado

Salida principal B — — — máx. 21 dBu, no balanceado

Cabina — — máx. +13 dBu —

Salida de pletina típico 0 dBu

Envío — typically 0 dBu — —

Envío micro auxiliar — — — -∞ a +6 dBu

Salida de auriculares típico 125 mW @ 1% THD típico 125 mW @ 1% THD típico 125 mW @ 1% THD máx. 180 mW @ 75 Ω

SUBWOOFER

Salida subwoofer — — — XLR balanceado

Separación de canales — — — Variable 30 - 200 Hz

Nivel — — — -∞ a 0 dBu @ entrada 0 dB

ECUALIZADOR

Graves stereo +12 dB/-32 dB @ 50 Hz

Medios stereo — +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz

Agudos stereo +12 dB/-32 dB @ 10 kHz

Graves micro — +12/-12 dB @ 50 Hz +12/-12 dB @ 50 Hz +15/-15 dB @ 80 Hz

Medios micro — — — +15/-15 dB @ 2.5 kHz

Agudos micro — +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz

Graves Kill — — -54 dB @ 50 Hz —

Medios Kill — — -44 dB @ 1 kHz —

Agudos Kill — — -26 dB @ 10 kHz —

USB

Audio Entrada/salida stereo

Conector Tipo B

Convertidor 16 bits

Frecuencia de muestreo 48 kHz

ESPECIFICACIONES DEL SISTEMA

Relación señal-ruido >88 dB (línea) >86 dB (línea) >85 dB (línea) >80 dB (línea)

Crosstalk o cruce de canal >67 dB (línea) >77 dB (línea) >77 dB (línea) <-70 dB (línea)

Distorsión (THD) <0.025% <0.06% <0.05% <0.05%

Respuesta de frecuencia 20 Hz - 20 kHz

Ajuste de ganancia de entrada -20 dB - +9 dB

ALIMENTACION

Voltaje

EE.UU./Canadá 120 V~, 60 Hz

Reino Unido/Europa/SAA/CCC 230 V~,50 Hz

Japón 100 V~, 50-60 Hz

Consumo máx. 10 W máx. 13 W máx. 22 W 22 W

Fusible
