Clock Source Mode MADI Configuration

Sample Rate Channels

MADI 44.1 kHz 64 ch

48 kHz 64 ch

MADI 2X 88.2 kHz 32 ch

96 kHz 32 ch

MADI 4X 176.4 kHz 16 ch

192 kHz 16 ch

Clock Source ADAT options: (Note that there is no S-Mux check-box for ADAT as it is

automatically enabled when you select ADAT 2X or ADAT 4X):

Clock Source Mode MADI Configuration

Sample Rate Channels

ADAT 44.1 kHz 8 ch

48 kHz 8 ch

ADAT 2X 88.2 kHz 4 ch

96 kHz 4 ch

ADAT 4X 176.4 kHz 2 ch

192 kHz 2 ch

5. Sample Rate select

6. Lock light

7. Presets

8. Audio source selector

9. Device selector

10. Settings

11. Info

12. Minimize

13. Close

14. Monitor volume knob

15. Mute output

16. Sessions – manage, save, load *

* By saving and loading your sessions using the two buttons on the right of the control

panel, you can always keep files for every song that you work on (recording, mixing,

mastering).

Once you click save, you can select what you would like to save from all the settings. For

example, save the Mixer settings, AFX, Digital I/O, etc.
