CHAUVET Data Stream 8 [11/13] Echnical

Data Stream 8 User Manual Rev. 1

TECHNICAL

Page 9 of 11

6. TECHNICAL SPECIFICATIONS

Dimensions and Weight

Note: Dimensions in inches rounded to the nearest hundredth.

Power

Thermal

DMX

Ordering

LENGTH WIDTH HEIGHT WEIGHT

19 in (483 mm) 5.2 in (132 mm) 1.7 in (44 mm) 4.6 lb (2.0 kg)

POWER SUPPLY TYPE RANGE VOLTAGE SELECTION

Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging

PARAMETER 120 V, 60 HZ 230 V, 50 HZ

Consumption 2 W 2 W

Operating Current 0.04 A 0.3 A

Fuse F 1 A, 250 V F 1 A, 250 V

POWER I/O U.S./CANADA WORLDWIDE

Power input connector IEC IEC

Power output connector Edison IEC

Power Cord plug Edison (U.S.) Local Plug

MAXIMUM EXTERNAL TEMPERATURE COOLING SYSTEM

104 °F (40 °C) Convection

I/O CONNECTOR

3-pin XLR

PRODUCT NAME ITEM CODE UPC NUMBER

Data Stream 8 09111451

781462217990
