STErEO INPUTS

The EON ONE has two stereo inputs and these are used primarily for MP3 or CD players but could be used with

the stereo output of an electronic keyboard, instrument pre-amp or processor, or an electronic drum machine�

The inputs labeled “CH 3/4” offer the option of using ¼" phone plugs or RCA plugs and this channel has a volume

control� The input labeled “CH 5/6” is a 3�5 mm stereo input of the type typically found on personal music players�

This input does not have a volume control as personal music players usually have a “volume control” built into the

unit� This is the best way to control the volume of the unit plugged into this input�

“CH 5/6” 3�5 mm input jack

for use with personal music

players

Volume control for “STEREO IN 3/4”

Stereo in 3/4 RCA inputs

(use with MP3 Player,

CD, or any consumer

type electronics)

Stereo in 3/4 1/4" phone inputs

(use with electronic keyboard,

instrument pre-amp or processor, or an

electronic drum machine)

STErEO MONITOr OUTPUTS

These outputs allow you to route the stereo mixer signal to another destination like a

recording device, personal monitor, or to another PA system�

MASTEr VOlUME & lIMIT lED

Your EON ONE is equipped with a “Master Volume” that controls the overall output

volume of the system and a Yellow LED that indicates that you have approached the

maximum output�
