JBL EON One [12/16] Section 5 system specifications

EON ONE

System

System Type: Portable Line Array with powered mixer

Maximum SPL Output: 118 dB peak system output (pink noise)

Frequency Range (-10dB): 37�5Hz – 18�5kHz

Frequency Response (-3dB): 45Hz – 18kHz

AC input : 100 - 120 VAC, 220-240 VAC 50/60 Hz

Amplier

Design: Class D

System Power Rating: 250 Watts LF, 130 Watts HF

Mixer

Input Connectors: 6 inputs (2 Mono Mic/Line, 2 x Stereo)

Channels:

1-2 are XLR / 1/4" jack combo connectors

(XLR is a mic level input, 1/4" is a line level input)

3-4, one pair of 1/4" balanced TRS jacks (stereo), and a pair of RCA jacks (stereo)

5-6 is a 3�5 mm stereo jack

Input Impedance: Ch 1-2 Combo: XLR 40 K Ohms Balanced

Ch 1-2 Combo: TRS 40 K Ohms Balanced

Ch 3-4: TRS 20 K Ohms Balanced

Ch 3-4: RCA 5 K Ohms Unbalanced

Ch 5-6: 3�5 mm 10 K Ohms Unbalanced

Output Connectors: Monitor outputs: one pair of RCA jacks (stereo)

Signal Indicators: Limit: Yellow LED indicates limiter active condition

EQ: Individual channel Bass and Treble controls, center detent, +/-12 dB cut and boost

System Limiter: On Board DSP Limiting and Tuning

Speaker

LF Driver: 1 x 254mm (10 in) woofer

HF Driver: 6 x 2" drivers

Coverage Pattern: 100º x 50º nominal

Enclosure: Polypropylene

Grille: Powder coated perforated steel

Dimensions (H x W x D)

Unit Dimensions:

Packaged Dimensions:

23.3" x 14.5" x 17" (593mm x 369mm x 434mm)

30.9" x 15.6" x 22.5" (769mm x 397mm x 572mm)

Net Weight of System: 18.51 kg (40.8 lbs)

Section 5: System Specications
