JBL EON One [10/16] Bluetooth input the eon one comes equipped with the ability to stream bluetooth audio to connect a bluetooth device first press the bluetooth pair button on the back of the eon one then select eon one from the source device to complete the pairing once paired the blinking bluetooth led will turn solid and audio can be streamed from the connected device

MONO MIC/lINE INPUTS

Moving from left to right there are 2 identical input strips comprised of (from top to bottom) a treble control,

bass control, reverb control, reverb on/off button, volume control, mic/line selector and a XLR 1/4" combination

connector�

Treble control adjusts the amount of high

frequencies on the particular channel

Bass control adjusts the amount of low

frequencies on the particular channel

Combination 1/4" phone plug and

XLR male input

Effect control adjusts the amount of

effect on the particular channel

Channel Volume control adjusts the

gain on the particular channel

MIC/LINE “SELECTOR” allows you to

select between a microphone (XLR)

input and a line (1/4" phone) input

BlUETOOTH INPUT

The EON ONE comes equipped with the ability to stream Bluetooth audio� To connect a

Bluetooth device, rst press the BLUETOOTH PAIR button on the back of the EON ONE. Then

select "EON ONE" from the source device to complete the pairing� Once paired, the blinking

BLUETOOTH LED will turn solid and audio can be streamed from the connected device�
