GCWR (Gross Combined Weight Rating)/Trailer weights
Engine
Rear
axle
ratio
Maximum
GCWR - kg
(lbs.)
Trailer weight range
(0-maximum) - kg
(lbs.)
4x2 with 17 inch wheels
5.4L-4V 3.73
6 577
(14 500)
0-4 037
(0-8 900)
4x4 with 17 inch wheels
5.4L-4V 3.73
6 350
(14 000)
0-3 674
(0-8 100)
Maximum frontal area of trailer is 5.6 square meters (60 square feet)
Do not exceed the maximum loads listed on the Safety Compliance
Certification label. For load specification terms found on the label, refer
to Vehicle loading in this chapter. Remember to figure in the tongue
load of your loaded trailer when figuring the total weight.
Towing trailers beyond the maximum recommended gross trailer
weight exceeds the limit of the vehicle and could result in
engine damage, transmission damage, structural damage, loss of control
and personal injury.
Preparing to tow
Use the proper equipment for towing a trailer, and make sure it is
properly attached to your vehicle. See your dealer or a reliable trailer
dealer if you require assistance.
Hitches
Do not use hitches that clamp onto the vehicle’s bumper or attach to the
axle. You must distribute the load in your trailer so that 10%–15% of the
total weight of the trailer is on the tongue.
Load equalizing hitch
When hooking up a trailer using a load equalizing hitch, always use the
following procedure:
1. Park the unloaded vehicle on a level surface. With the ignition on and
all doors closed, allow the vehicle to stand for several minutes so that it
can level.
Driving
173
