Husqvarna 435e (2009) parts [19/39] Page g 435 435e 440e

Page G 435, 435e, 440e CARBURETOR & AIR FILTER

Position Article Quantity Notes Kit

504 72 47-01 1 Insulation wall assy

504 72 45-01 1 Insulation wall rubber 1

504 72 44-01 1 Inulation wall plastic 1

504 20 12-01 1 Inlet pipe

503 20 02-16 4 Screw

506 45 05-01 1 Carburettor

7 544 28 44-01 1 Throttle rod assy

8 544 97 64-01 1 Filter holder assy

9 544 39 26-01 1 Shackle

10 504 71 25-01 1 Guide sliding shoe

11 544 84 43-02 1 Control assy

12 544 97 66-01 1 Screw

503 20 02-40 3 Screw

544 80 54-02 1 Air ﬁlter assy (44 micron)

544 80 54-03 1 Air ﬁlter assy (felt)

15 503 93 66-01 1 Air purge

16 544 40 19-01 1 Hose, airpurge suction
