Husqvarna 435e (2009) parts [5/39] Page a2 435

Page A2 435 CHAIN BREAK & CLUTCH COVER

Position Article Quantity Notes Kit

501 38 82-01 Clutch cover assy

735 31 08-20 1 E-clip 1

537 28 66-01 1 Pawl 1

540 06 33-01 1 Chain guide 1

537 01 74-01 1 Bearing sleeve 1

503 89 08-02 1 Knee joint 1

505 89 26-01 1 Brake spring 1

503 85 52-01 1 Guide bushing 1

544 24 85-01 1 Cover lid 1

503 21 70-10 7 Screw 1

544 25 31-01 1 Wear protection 1

544 30 60-01 1 Brake band assy 1

503 89 29-01 1 Pin 1

537 39 70-01 1 Worm screw 1

537 07 94-02 1 Worm wheel 1

740 48 07-02 1 O-ring 1

503 23 00-63 1 Washer 1

544 37 68-01 1 Label, clutch cover 1

19 503 22 00-01 1 Nut
