Husqvarna 435e (2009) parts [33/39] Page n 435 435e 440e

Page N 435, 435e, 440e CARBURETOR DETAILS

Position Article Quantity Notes Kit

506 45 05-01 1 Zama C1T-EL41

503 48 11-01 1 Piece 1

504 02 40-01 1 Nozzle assy 1

503 53 56-01 1 Plug welch 1

503 47 97-01 1 Valve 1

537 02 03-01 1 Spring 1

503 66 59-01 1 Lever 1

503 48 00-01 1 Pin retaning screw 1

504 02 41-01 1 Screw 1

505 53 52-01 1 Cap 1

504 02 61-01 1 Shaft assy 1

505 11 07-01 1 Collar 1

504 02 85-01 1 Spring 1

504 02 75-01 1 Valve 1

503 48 18-01 2 Screw 1

504 02 67-01 2 Circlip 1

504 02 62-01 1 Shaft assy 1

540 05 37-01 1 Lever 1

504 02 83-01 1 Spring 1

504 02 63-01 1 Lever 1

503 47 90-01 2 Screw 1

504 02 74-01 1 Valve 1

503 48 18-01 2 Screw 1

504 02 60-01 1 Shaft assy 1

504 02 84-01 1 Spring 1

544 98 31-01 1 Lever 1

503 47 90-01 2 Screw 1

504 02 76-01 1 Valve 1

503 47 92-01 1 Screw 1

504 02 73-01 1 Screw 1

504 90 92-01 1 Screw 1

504 02 81-01 1 Screw 1

504 02 43-01 1 Gasket 1, 42

504 02 45-01 1 Diaphragm 1, 42

504 02 46-01 1 Body 1

504 02 82-01 1 Screw 1

504 02 50-01 1 Strainer 1

504 02 56-01 1 Diaphragm 1, 42

504 02 57-01 1 Gasket 1, 42

504 02 59-01 1 Cover 1

504 02 78-01 4 Screw 1

42 504 02 86-01 1 B= Set of Gaskets
