Chapter 1. 1-6

4. Tighten the screw to secure the Tiny.

Part 3: Install the rear Wi-Fi antenna (optional).

1. Pivot the cable cover as shown to the open position. Then, press the decorative cover 2

from the inner side of the cable cover to remove the decorative cover.

2. Screw the rear Wi-Fi antenna to the antenna connector on the rear of the computer. Then,

adjust the angle of the antenna to 90 degrees.
