Connecttherear-panelAUX.OUTjacktoamplified
speakers,amplifiersordomestichi-fi-unitsfor
externalamplification.
NOTE:
Connectbothleft(L)andright(R)channelsforthestereo
result.
Ifyouonlyconnecteitheroneofthechannels,the
connectedchannelwillonlytakeeffect.
UsingtheAUX.OUTJack
AUX.OUT
PEDAL
1.
2.
Headphones
Jack1
Headphones
Jack2
UsingHeadphones
Therearetwoheadphonejacksontheleftunderneath
thepianobody.
Whenanoptionalsetofstereoheadphonesisconnected
withtheheadphonesjack2,thesoundfromspeakers
willswitchoffautomaticallyresultinginonlysoundfrom
headphonetobeheard.
Whenjack1isconnectedwithstereoheadphones,the
soundcanbeheardfrombothheadphonesandspeakers
ofthepiano.
NOTE:
Neveruseheadphoneswithhighvolume,asitmay
damageyoursenseofhearing.
Topreventdamagingthespeakers,ensurethatthe
volumeissettotheminimumlevelbeforeconnecting
thepowerandotherdevices.
Connection
WARNING
Toavoiddamages,pleasebesuretoturnoffthepower
switchesbeforeyoudisconnecttherelateddevicesfrom
thepiano.
MIDIstandforMusicalInstrumentDigitalInterface.
MIDIisaworldwidestandardthatmakesitpossiblefor
variouselectronicmusicalinstrumentsandotherdevices.
MIDIIN:
MIDIOUT:
DatatransmittedfromotherMIDIinstrumentviaMIDIis
receivedbythisterminal.
DataproducedbytheDigitalPianoistransmittedtoother
MIDIinstrumentsviaMIDIfromthisterminal.
MIDIIN/OUTJack
8
AUX.OUT
PEDAL
14
