AUX.OUT
MIDIFunction
49
WhatisMIDI
MIDIConnection
1
2
3
1
2
ConnecttheMIDIinterfacewithotherdigitalmusicinstruments.
MusicalInstrumentDigitalInterface.Thestandard
interfacebetweenPCandElectronicinstrument.
ItisequippedwithstandardMIDIinterface,including
1MIDIINand1MIDIOUT.
Connection
ItcanconnectwithPCorotherMIDIequipment.
’’
Inmidiconnection,theequipmentwhichcontrolsanotherequipmentiscalledHostEquipment.
AnotherequipmentiscalledAffiliatedEquipment.
ThehostequipmentsMIDIOUTconnectwithaffiliatedequipmentsMIDIIN.
DonotconnectMIDIOUTwithMIDIINonthesameequipment.
Connectionrule
SampleConnectionMethod
ConnecttheMIDIinterfacewithyourPC.
MIDIIN
MIDIOUT
YoucanuseaMIDIcabletoconnecttheMIDIINterminalofsystemtoanotherMIDIOUTterminalofcompatibleMIDI
electronicinstrument.UseMIDIIN,systemcanreceivemididatasuchasnote,programandtouchetc.inordertobe
handledbyanotherMIDIinstrument.
YoucanuseaMIDIcabletoconnecttheMIDIOUTterminalofsystemtoanotherMIDIINterminalofcompatibleMIDI
electronicinstrument.MididataofsystemcanbesentbyMIDIOUT,whenanoteisgenerated,therelativemessagewill
betransmitted.Systemcancontrolothermidiinstrumentbysendingprogramchangemessages
，
3
