Husqvarna T425 (2008) parts [11/27] Page e t425

Page E T425 ROTOR ASSY, MODULE ASSY

Position Article Quantity Description Kit

1 505 04 15-01 1 NUT

2 * 525 73 84-01 1 FLYWHEEL ASSY

3 505 04 22-01 2 PAWL 2

4 505 04 23-01 2 SPRING 2

5 505 04 24-01 2 SCREW 2

6 505 04 25-01 2 WASHER 2

7 * 525 73 81-01 1 MODULE ASSY

10 525 61 55-01 1 CAP 7

12 505 04 33-01 1 GROMMET 7

13 505 04 34-01 2 SPACER

14 505 04 35-01 2 BOLT

15 503 23 51 08 1 Spark plug RCJ7Y

16 505 04 37-01 1 CORD

17 505 04 38-01 1 CORD

* See Service Bulletin B0900015
