Husqvarna T425 (2008) parts [3/27] Page a t425

Page A T425 BRAKE ASSY

Position Article Quantity Description Kit

1 505 05 04-01 1 BRAKE ASSY

3 505 05 06-01 1 GUARD 1

4 505 05 07-01 1 SPRING 1

5 505 05 08-01 1 SCREW 1

6 505 05 09-01 1 SPACER 1

7 505 05 10-01 1 SPACER 1

8 505 05 11-01 1 WEIGHT 1

9 505 05 12-01 1 SPRING 1

10 505 05 13-01 1 SPRING 1

11 505 05 14-01 1 WASHER 1

12 505 05 15-01 1 NUT 1

13 505 05 16-01 1 LEVER C 1

14 505 05 17-01 1 ROLLER 1

15 505 05 18-01 1 ARM 1

16 505 05 19-01 1 BAND 1

17 505 05 20-01 1 ROLLER 1

18 505 05 21-01 1 SPRING 1

19 505 05 22-01 1 COVER. SPRING 1

20 505 05 23-01 4 SCREW 1

21 505 05 24-01 1 PLATE(B) 1

22 505 05 25-01 1 SCREW 1

23 505 05 26-01 1 NUT 1

24 505 05 27-01 1 GEAR 1

25 505 05 28-01 1 NUT

26 505 05 90-01 1 DECAL. CLUTCH COVER
